HRB P/N definition: M5035/M5036 ① Pole number ② Color ③ Side wall ④ solid rib Rast 5 connector for direct mating, alternatively with or without side wall/solid rib, with screw terminal.
HRB P/N definition: M5037/M5038 ① Pole number ② Color ③ Keying code ④ Lock code Rast 5 connector for direct/indirect mating, with interior locking, with screw terminal.
HRB P/N definition: M5039/M5040 ① Pole number ② Color ③ Keying code ④ Lock code Rast 5 connector for indirect mating, with interior locking, with screw terminal, with/without handle latch.
HRB P/N definition: M5041/M5042 ① Pole number ② Color ③ Keying code ④ Lock code Rast 5 tab header, with test holes, with screw terminal, with/without handle latch.
Versatile PCB Connector Solutions
Our highly-reliable RAST 5 printed circuit board connectors, with their standardized mating face, meet all requirements of the RAST 5 standard, as well as those for fire protection and resistance according to DIN EN 60335-1. With its variety of molded-in coding, the system prevents misplacing, offering both connection and operational reliability, as well as enormous advantages during final installation.
HRB Printed Circuit Board Connector SPECIAL SOLUTION FOR THE +Heating industry +Household appliance industry
Household Appliance Industry
Elevator
Heat Pumps
Hotel Central Air Conditioning And Heated Curtains
HVAC
Motors On The Rollers Gravitational
High-Quality PCB Screw Terminals
HRB PCB connectors enables simple, fast and safe mounting.
1.M5035, M5036, and M5037 series, direct mating with PCB. Printed circuit board connectors plugged straight on to the board without soldering. 2.M5038, M5039, and M5040 series, indirect mating with PCB, which is mating with header(M940X series) directly, then mating with PCB.
Features:
● No headers required, mating directly with printed circuit board simply.
● Mounting side by side without loss of holes. ● Mating protection prevents misplacing, no worries about mistakes. ● Varieties of coding, to have many different coding options for customer's demand.
Advantages:
● Mating without tools, no soldering required. ● Various PCB thickness, from 1.36mm to 1.64mm. ● Allows Various wire connection. ● Number of mating cycles > 50 through spring-loaded contacts. ● Mounting tool unnecessary. ● Touch safely.
This product is really surprising! Its functions are powerful and practical, with first-class quality and exquisite appearance design. It is very convenient to use and the user experience is very pleasant. Highly recommended to everyone!
The design of this product is really user-friendly, and its user experience is very smooth, making me feel very comfortable. Moreover, its appearance is also very exquisite, which really makes me love it.
This product has a very high cost performance ratio, powerful and practical functions, and is definitely your best choice. The manufacturer's after-sales service attitude is first-class, making people worry free. Very satisfied!
The HRB 4.0mm waterproof auto connector series meets the four specifications of 8.14.23.35. The A-M4022-2XN-C series is matched with the M4021/4021R series double-row cable ends. It is IP67 waterproof and dustproof and is widely used in all types of cars. Electrical, ATV, Yacht LiDAR, UAV and other products
HRB 6.35mm waterproof connector master shell wire-to-wire wire-to-board Power terminal meets 30A 250V electrical performance Suitable for all types of yachts, drones, ATVs and other applications
3.0mm waterproof connector masterbatch shell multi-PIN single row double row wire-to-wire & wire-to-board PBT UL94V-O material power terminal 10A current 250V Suitable for lawn mowers, yachts, power tools, outdoor lighting and other applications
Field wiring type top lock screw fixation front threading 90 degree outlet for direct or indirect matching, suitable for wire-to-board and wire-to-wire connectors under the piercing process.Keying according to RAST 5 standard to avoid pairing errors.RAST5.0 power connector signal and current load up to 10A, pitch 5.0mm
The product spacing is 2.0mm double row, 2*2-2*12 full series, the appearance is milky white, 90° curved needle and 180° straight needle, which can be easily matched with the wire end M20032s.Perfectly plugged in, not easy to fall off, and easy to disassemble, it can reach IP67 waterproof rating, giving it a full range of experience design effects.This product is divided into regular version and easy-plug version. This model is the easy-plug version.The product has obtained UL certification and SGS environmental certificate!
Waterproof connector 6PIN, double row, 2*3/2*4, two easy-to-plug female rubber shells adapted to T20033PS-2 male end AWG22-26 PBT UL94V-O material IP67 waterproof rating
HRB2.5mm waterproof male case series double row M2531R series is matched with M2532 series double row cable ends, IP67 level waterproof and dustproof, widely used in various types of automotive appliances, lidar, drones and other products
The product spacing is 2.0mm double row, 2*2-2*12 full series, the appearance is milky white, 90° curved needle and 180° straight needle, which can be easily matched with the wire end M20032s.Perfectly plugged in, not easy to fall off, and easy to disassemble, it can reach IP67 waterproof rating, giving it a full range of experience design effects.This product is divided into regular version and easy-plug version. This model is the easy-plug version.The product has obtained UL certification and SGS environmental certificate!
Waterproof connector 4PIN, single row with 2-4 positions, easy-to-plug female rubber shell adapted to T20033PS-2 male end AWG22-26 PBT UL94V-O material IP67 waterproof rating
Field wiring type top lock screw fixation front threading 90° cable outlet for direct or indirect matching, suitable for wire-to-board and wire-to-wire connectors under the piercing process.Keying according to RAST 5 standard to avoid pairing errors.RAST5.0 power connector signal and current load up to 10A, pitch 5.0mm
These are conceptually plugs & sockets used by us in daily life. These are used for heavy duty applications. Plug means the part which bears the coupling nut and which is free when unmated. Receptacle is the mating component which is normally fixed to the equipment except for the cable connector where both mating parts are free.
What Are The Applications For These Circular Shell Threaded Coupling Connectors?
It is difficult to determine all the applications for these circular shell threaded coupling connectors. They are available for many applications from commercial / industrial use to the most stringent, high reliability military and space applications. Since they provide for minimum effort in usage, they are high economy upgrades for existing applications and provide simplified design for new and interphase equipment.
How Are Today'S Connectors Different Than Those In The Past?
In the past connectors simply passed voltage between two points. Today’s connectors must meet the complex needs of modern system by allowing the incorporation of multiple medias, such as power, singal, coax, eternet, fiber optics and pneumatics cabling into a single connector. A rectangular connector can easily combine multiple medias into a single connector using standard modules that can be easily arranged into a custom solution. Systems using circular connectors still require separate connector for ethernet, fiber optic, and coax power.
What Kinds Of Connectors Can Engineers Specify For Machine Designs Today?
Design engineers have two choices for industrial electrical connectors: Circular and rectangular. Circular connectors have a long history in military applications and in food and beverage processing. Rectangular connectors are used widely in modular machine design, factory automoation, robotics, transportation and power generation. Both have benefits, for example, circular connectors are advantageours when a cable is passing through a cable tray. Rectangular connectors offer other benefits, such as easy customization with standard moudules and space saving.
