Q: What is the temperature rise requirement for this connector?
A: The temperature rise test shall be performed under rated current of 3.2A DC, using 22AWG wire in still air laboratory ambient. The maximum allowable temperature rise ΔT is 30°C.
Q: What is the terminal retention force requirement of this connector?
A: The axial pullout test shall be conducted at a speed of 25.4 ± 6 mm/min. The minimum terminal retention force in housing is 24.5 N.
Q: What is the housing lock strength requirement for this connector?
A: After mating the connectors, apply axial pull-out force opposite to insertion direction at a speed of 1~5 mm/sec. The housing lock strength shall be ≥50 N.
Q: What is the vibration test requirement for this connector?
A: After mating the connector, the vibration test sweeps 10 Hz ~ 500 Hz and back to 10 Hz within 15 mins. Run 12 cycles on each of 3 mutually perpendicular directions (36 cycles total, ~9 hours). Requirements: No damage on appearance; max contact resistance ≤20 mΩ; discontinuity ≤1 microsecond.
Q: What is the IPX7 waterproof test requirement for this connector?
A: Immerse the mated connector sample in 1m deep water for 30 minutes. After testing, contact resistance ≤20 mΩ, and no breakdown under 500 VAC dielectric withstanding voltage.
Q: What cable requirements apply to this connector?
A: Wires with insulation outer diameter less than Φ1.4 mm are not allowed. In principle, solid wire, tin-coated wire, shielded wire and other special wires are not applicable.
Q: What are the storage requirements for HRB 2.0mm pitch waterproof connectors?
A: Store the connectors in original carton / product box or bag. After opening the carton, re-pack the goods. Recommended storage environment: temperature 5°C ~ 35°C, relative humidity 45% ~ 60%. Keep away from direct sunlight, corrosive gas, dust and condensation.
Q: What are the storage requirements for HRB 2.0mm pitch waterproof connectors?
A: Store the connectors in original carton / product box or bag. After opening the carton, re-pack the goods. Recommended storage environment: temperature 5°C ~ 35°C, relative humidity 45% ~ 60%. Keep away from direct sunlight, corrosive gas, dust and condensation.
