The reason why a circular connector is called a circular connector is that it is circular, and it is distinguished between waterproof and non-waterproof. It is the most used connector in the industrial field. There are more than 10,000 companies in the world producing circular connectors. Shaped connector products. Very reliable applications in the aerospace industry automation field have a history of more than 100 years.
Most of the plugs and sockets of circular connectors are connected by screw threads, and the terminals can range from two to hundreds. They have the characteristics of small size and high reliability, which can meet the needs of cable connection between electronic devices. We are going to talk about the basic structure of the circular connector and Circular connector application.
Here is the content list:
l The basic structure of the circular connector
l Circular connector application
The basic structure of the circular connector
1. Contacts
The contact is the core part of the circular connector to complete the electrical connection function. Generally, a contact pair is composed of a female contact piece and a male contact piece, and the electrical connection is realized by the insertion of the female contact piece and the male contact piece.
2, Possession
Accessories are divided into structural accessories and installation accessories. Structural accessories such as positioning pins, clamp rings, coupling rings, sealing rings, guide pins, positioning keys, cable clamps, gaskets, etc. Install accessories such as spring rings, screws, screws, nuts, etc. Most of the accessories have common parts and standard parts.
3, insulator
The insulator is also often called the base or the mounting plate. Its function is to arrange the contacts according to the required position and spacing and to ensure the insulation performance between the contacts and between the contacts and the housing.
4, shell
Shell, also called the shell, is the outer cover of the circular connector. It provides mechanical protection for the built-in insulating mounting plate and pins, and provides the alignment of the plug and socket when mating, and then fixes the connector to the device.
Circular connector application
The cylindrical structure of the circular connector has natural sturdiness and a higher strength-to-weight ratio than any other shape. It is easy to machine with standard machine tools. It is easier to seal, easy to insert, and disconnect. Simple and firm locking mechanism. Ten years of technological development has given it a complete and reasonable process and high reliability. Therefore, it is required to use the multi-contact connector to realize the interconnection between the component and the cable, and the circular connector is the first choice.
It is the responsibility of each manufacturer to produce circular connectors that meet the standards. Shenzhen Hongru Connector Co., Ltd. conducts many tests on circular connectors before they leave the factory, and the quality qualification rate is guaranteed. If you are in the circular connector business, you can consider our cost-effective products.
