Specification:
Current rating: 4A AC,DC
Voltage rating: 250V AC,DC(3-4 PIN)
60V AC, DC(5 PIN)
Operating temperature: -40℃~+120℃
Contact resistance: 10mΩ max.
Insulation resistance: 100MΩ Min.
IP grade: IP67
Durability: ≥500 times
Diameter: ∅1.0±0.03mm
Insulation material: PA66 UL94V-0
Terminal material: brass, gold plated contact area
Shell material: copper alloy nickel/zinc alloy nickel/stainless steel
Wiring: Soldering
Seal ring: Silicone
Wire size : ≤0.5mm²(AWG#20)
Coding:
HRB P/N chart:
| P/N | Pole | Shell material | P/N | Pole | Shell material |
| M12005‐L0‐3‐B‐Z‐X | 3 | zinc alloy nickel | M12005‐L0‐5‐B‐Z‐X | 5 | zinc alloy nickel |
| M12005‐L0‐3‐B‐C‐X | copper alloy nickel | M12005‐L0‐5‐B‐C‐X | copper alloy nickel |
| M12005‐L0‐3‐B‐S‐X | stainless steel | M12005‐L0‐5‐B‐S‐X | stainless steel |
| M12005‐L0‐4‐B‐Z‐X | 4 | zinc alloy nickel |
|
|
|
| M12005‐L0‐4‐B‐C‐X | copper alloy nickel |
|
|
| M12005‐L0‐4‐B‐S‐X | stainless steel |
|
|
